Hercules
HERKULES 400
Dimensions:
| Number of wheels |
Lenght [mm] | Width [mm] |
Hight [mm] |
Wheel base [mm] | Wheel diameter [mm] |
|---|---|---|---|---|---|
| 4 | 1340 | 690 | 1364 | 915-965 | 315 |
Technical data:
| Number of engines / Engine power [W] |
Maximum driving speed [km/h] |
* Approx. range [km] |
Acceptable load [kg] |
Capacity of an accumulator [Ah] |
|---|---|---|---|---|
| 2x400 | 13 | 45-55 | 140 | 75 |
HERCULES
Dimensions:
| Number of wheels |
Lenght [mm] | Width [mm] |
Hight [mm] |
Wheel base [mm] | Wheel diameter [mm] |
|---|---|---|---|---|---|
| 4 | 1340 | 690 | 1364 | 915-965 | 315 |
Technical data:
| Number of engines / Engine power [W] |
Maximum driving speed [km/h] |
* Approx. range [km] |
Acceptable load [kg] |
Capacity of an accumulator [Ah] |
|---|---|---|---|---|
| 2x200 | 13 | 45-55 | 140 | 75 |
* The real range depends on the mass of the user and the type of the terrain on which the wheelchair moves as well as on a correct using of accumulators (according to the manual).
